CABOCHONS

Amusement Park Spares Ltd are have been supplying Cabochon Lights for over 20 years to the UK Amusement Ride Industry. We can supply either from stock or direct from Italy on our regular Import Service. Various of makes of Cabochon can be supplied, from ECO and VSV to Imel Park. This saves you time and cost of Transport as we consolidate our orders into one shipment.

Click on the PDF below to view even more products.

You can enquire about any of our Cabochon products by clicking the enquiry link below.

E10 Cabochons

A extremely reliable product which is resistant to accidental damage and unscrewing of the pieces thanks to its sturdier construction and improved thread. Excellent Quality. All the sockets used are certified to CE and UL Standards.

Perfect for all Amusement Rides.

E10/E14 Locking Cap
Part No : 303

Locking Cap nut for sockets pl302, PL307, PL308.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E10 Lampholder ( Blade Socket )
Part No : 307

E10 Screw Socket.

To be used with DA303, for base BA324 and ringnut GH371 and GH361.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E10 Lampholder ( Soldering Socket )
Part No : 306

E10 Soldering Socket.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E10 Cap Clear
Part No : 325-S1

Cap E10 Clear for BA324.


Made in Italy.

For prices contact us on email : amtpkspares@btconnect.com
E10 Base Clear
Part No : 324-S1

Base E10 Clear, to use with cap CA325, and socket PL306 or PL307.

Use PL303 Locking Nut

Made in Italy.

For price contact us on email : amtpkspares@btconnect.com
E10 Cap Red
Part No : 325-S8

Cap E10 Red for BA324.


Made in Italy.

For prices contact us on email : amtpkspares@btconnect.com
E10 Base Red
Part No : 324-S8

Base E10 Red, to use with cap CA325, and socket PL306 or PL307.

Use PL303 Locking Nut

Made in Italy.

For price contact us on email : amtpkspares@btconnect.com
E10 Cap White
Part No : 325-S2

Cap E10 White for BA324.


Made in Italy.

For prices contact us on email : amtpkspares@btconnect.com
E10 Base White
Part No : 324-S2

Base E10 White, to use with cap CA325, and socket PL306 or PL307.

Use PL303 Locking Nut

Made in Italy.

For price contact us on email : amtpkspares@btconnect.com
Show More

E14 Cabochons

The Characteristics of this product are identical to those of Model E10 but this version is larger. All the sockets are certified to CE and UL Standards.

308 Lampholder E14
Part No : 308

To be used with 303 and BA321 or GH312+BA320.

Made in Italy.

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E14 Lampholder ( Blade Socket)
Part No : 302N

E14 screw type Lampholder.

To be used with 303

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E14 Lampholder ( Solder Socket )
Part No : 301

E14 Lampholder ( Solder ) for
base BA320 and BA321.

Made in Italy.

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E14 Rubber Washer
Part No : RG323

Rubber Washer E14

For E14 lampholders PL301,pl302n,PL308

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E10/E14 Locking Cap
Part No : 303

Locking Cap nut for sockets pl302, PL307, PL308.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E14 Cap Clear
Part No : 322-S1

Cap E14 Clear Cap.

For bases BA321, BA320 and PL351, GH361.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E14 Base Clear
Part No : 321-S1

For Cap CA322 and CA327, and socket PL301,pl302n,PL308.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E14 Cap Yellow
Part No : 322-S3

Cap E14 Yellow Cap.

For bases BA321, BA320 and PL351, GH361.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
E14 Base Yellow
Part No : 321-S3

For Cap CA322 and CA327, and socket PL301,pl302n,PL308.

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com or call us on 01926 833233
Show More

Cabochon Kits

We also supply Cabochons in complete kit form including your chosen Lamp or LED.

All our LEDs and Lamp are Italian made giving customers a quality and reliable product.

Click on the Link below to view our Lamps and LEDs.

E10 Clear Cabochon Kit
Cabochon Clear E10 Kit.

Complete w/screw type socket.
PL307+DA303+BA324S1+CA325S1.

(Bulb not included )

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E14 Clear Cabochon Kit
Cabochon Clear E14 Kit.

Complete w/screw type socket.

pl302n+DA303+BA321S1+CA322S1.

(Bulb not included)

Made in Italy
E10 Red Cabochon Kit
Cabochon Red E10 Kit.

Complete w/screw type socket.
PL307+DA303+BA324S1+CA325S1.

(Bulb not included )

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E10 White Cabochon Kit
Cabochon White E10 Kit.

Complete w/screw type socket.
PL307+DA303+BA324S1+CA325S1.

(Bulb not included )

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E10 Blue Cabochon Kit
Cabochon Blue E10 Kit.

Complete w/screw type socket.
PL307+DA303+BA324S1+CA325S1.

(Bulb not included )

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E14 Blue Cabochon Kit
Cabochon Blue E14 Kit.

Complete w/screw type socket.

pl302n+DA303+BA321S1+CA322S1.

(Bulb not included)

Made in Italy
E10 Fuchsia Cabochon Kit
Cabochon Fuchsia E10 Kit.

Complete w/screw type socket.
PL307+DA303+BA324S1+CA325S1.

(Bulb not included )

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E10 Yellow Cabochon Kit
Cabochon Yellow E10 Kit.

Complete w/screw type socket.
PL307+DA303+BA324S1+CA325S1.

(Bulb not included )

Made in Italy

For prices contact us on email : amtpkspares@btconnect.com
E14 Yellow Cabochon Kit
Cabochon Yellow E14 Kit.

Complete w/screw type socket.

pl302n+DA303+BA321S1+CA322S1.

(Bulb not included)

Made in Italy
Show More
Cabochon Nova 70.jpg

Cabochon Nova 70

Brighter and Quicker to Assemble. Watertight construction, compact and sturdy for exposed assemblies. RGB, Power White, Strobe or one colour.

All products are made in Italy to ensure the highest levels of quality are met.

For more information on any of the below products please get in touch.

Cabochon Nova 70 - Clear
Part No : 1500.ESA20/20C

Nova 12 LED RGB 24Vac 3,8W

Size d.70mm.

IP65

Diodes by Osram. Matrix program (up to 20ch x20ch).PLEASE SPECIFY IN THE ORDER N° OF Channels (2-20 by 2-20 channells ) OR program letter ( for spare parts).

Clear Lense.

Made in Italy

For prices please email us at amtpkspares@btconnect.com or call us on 01926 833233
Cabochon Nova 70 - Blue
Part No : 1510 - Single Colour

Nova 12 LED RGB 24VAC 3W

Available in 7 colours.

Size d.70mm.

IP65

Made in Italy

For prices please email us at amtpkspares@btconnect.com or call us on 01926 833233
Cabochon Nova 70 - Frosted
Part No : 1500.ESA20/20F

Nova 12 LED RGB 24Vac 3,8W

Size d.70mm.

IP65

Diodes by Osram. Matrix program (up to 20ch x20ch).PLEASE SPECIFY IN THE ORDER N° OF Channels (2-20 by 2-20 channells ) OR program letter ( for spare parts).

Frosted Lense.

Made in Italy

For prices please email us at amtpkspares@btconnect.com or call us on 01926 833233
Show More
Cabochon Nova 51.jpg

Cabochon Nova 51

Extremely compact package, both in front and rear. IP65 sealed construction. Custom effects with up to 24 channels or 24 x 24 ch ( matrix ). Clear or frosted lens. Also available as RGB, Power white or single colour. RGB with controller or pre programmed. Sizes d - 53mm, h - 13mm

All products are made in Italy to ensure the highest levels of quality are met.

For more information on any of the below products please get in touch.

Cabochon Nova 51 - Frosted
Part No : CA1700-ESA20-20F

Nova Spotlight 7LED RGB 24VAC 1,8W. LEDs by Osram.

Matrix Program up to 20 x 20 channels. Please Specify in your order N° Of Channels (from 2 to 20 by 2 to 20) OR Program Letter (FOR SPARE PARTS).

Frosted Lense.

Sizes:
Diameter 53mm, front Thickness 13mm, rear thickness 22mm.

IP67 protection index.

Made in Italy.

One year warranty, estimated lifespan 4-5 years.

For prices email us at amtpkspares@btconnect.com or call us on 01926 833233
Cabochon Nova 51 - Blue
Part No : CA1720-S7

Nova Spotlight 7LED RGB 24VAC 1,8W. LEDs by Osram.

Blue Lense.

Sizes:
Diameter 53mm, front Thickness 13mm, rear thickness 22mm.

IP67 protection index.

Made in Italy.

One year warranty, estimated lifespan 4-5 years.

For prices email us at amtpkspares@btconnect.com or call us on 01926 833233
Cabochon Nova 51 - Clear
Part No : CA1700-ESA20-20CL

Nova Spotlight 7LED RGB 24VAC 1,8W. LEDs by Osram.

Matrix Program up to 20 x 20 channels. Please Specify in your order N° Of Channels (from 2 to 20 by 2 to 20) OR Program Letter (FOR SPARE PARTS).

Clear Lense.

Sizes:
Diameter 53mm, front Thickness 13mm, rear thickness 22mm.

IP67 protection index.

Made in Italy.

One year warranty, estimated lifespan 4-5 years.

For prices email us at amtpkspares@btconnect.com or call us on 01926 833233
Cabochon Nova 51 - Yellow
Part No : CA1720-S3

Nova Spotlight 7LED RGB 24VAC 1,8W. LEDs by Osram.

Yellow Lense.

Sizes:
Diameter 53mm, front Thickness 13mm, rear thickness 22mm.

IP67 protection index.

Made in Italy.

One year warranty, estimated lifespan 4-5 years.

For prices email us at amtpkspares@btconnect.com or call us on 01926 833233
Show More
Extraplat 50-65mm.jpg

Extraplat 50/65

Extraplat 50/65 was designed to create maximum flexibility and compactness. To be installed with LEDs or Bulbs E10. Two sizes 50mm and 65mm available with Securtech chrome-plated or coloured rings.

All products are made in Italy to ensure the highest levels of quality are met.

For more information on any of the below products please get in touch.

Extraplat 50mm Complete
Part No : ID50E

Extraplat 50mm Cabochon complete with lampholder.GH371 + PL307 + DA303 + CA325.

All colours of CA325 Caps available on request.

Comes without lamp.

Made in Italy.

For prices email us at amtpkspares@btconnect.com or call us on 01926 833233
Extraplat 50mm Ring Nut
Part No : 371

Extraplat 50mm ring for PL307 + DA303 or PL306 lampholders.

Use with 325 Cap.

Size 56 mm.

Made in Italy

For prices email us at amtpkspares@btconnect.com or call us on 01926 833233
Extraplat 50mm
Part No : 341

Extraplat 50mm soldering socket for cap 325.

Made in Italy.

For prices email us on amtpkspares@btconnect.com or call us on 01926 833233
Wiring Insulator 50/65
Part No : 342

Wiring Insulator for 341 and 351 Extraplat 50/65

Made in Italy

For prices email us on amtpkspares@btconnect.com or call us on 01926 83323
Extraplat 65 Ring Nut
Part No : 361

Extraplat 65mm ring nut, for 307+303 or 306 sockets, use with 322 or 327

Made in Italy

For prices email us on amtpkspares@btconnect.com or call us on 01926 83323
Extraplat 65mm
Part No : 351

Extraplat 65mm Lampholder, for 322 and 327 caps (LED).

Made in Italy.

For prices email us on amtpkspares@btconnect.com or call us on 01926 833233
Show More
Trunking 5.jpg

Complete Trunking

Made to measure complete lighting trunking.

Let us know which specification you require.

All products are made in Italy to ensure the highest levels of quality are met.

For more information on any of the below products please get in touch.

Complete Trunking - Wiring
Complete Trunking - End Cap
Complete Trunking - Example Yellow & Clear
Complete Trunking - Example Clear & Pink
Complete Trunking - Example Blue & Clear
Show More
E14 Esaled Lamp.jpg

Accessories

A selection of Accessories including Cables, Securtech rings, rubber washers and much more.

All products are made in Italy to ensure the highest levels of quality are met.

For more information on any of the below products please get in touch.

Securtech E14
Securtech 65mm in Chromed Plastic

Ideal for Extraplat 65 " ID65"

Made in Italy

For more details please email us at amtpkspares@btconnect.com or call us on 01926 833233
Cable
Show More
